1970-1983 AMC Prothane Total Suspension Bushing Kit

$151.97

Vendor: Prothane

Description:

  • P/N 1-2011-BL - Black
  • Improves handling & reduces "spongy ride"
  • Impervious to gas and oil
  • Will not rot or deteriorate
  • Available in black
  • Made in the USA
  • Limited lifetime manufacturer warranty
  • Kit box dimensions:  18 x 6.8 x 12 inches
  • Kit box weight:  9.15 lbs.
AMC, American Motors, Rambler
Models Years
AMX 1970
AMX 1978
Concord 1978-1983
Gremlin 1970-1978
Hornet 1970-1977
Javelin 1970-1974
Javelin AMX 1971-1974
Spirit 1979-1983



Kit Includes:

1207

  • 4 of Upper Control Arm Bushings - 64229
  • 2 of Lower Control Arm Bushings - 64227
  • 2 of Lower Control Arm Thrust Washers - 64228
  • 2 of Metal Sleeves - 60818 (7/8 X 2.050 inches)
  • 4 of Metal Sleeves - 60819 (3/4 X 1.980 inches)
  • 3 of Super Grease - 19-1750-001

61205

  • 4 of Front Strut Rod Bushings - 60135
  • 2 of Metal Sleeves - 60755 - (7/8 X .083 X 2.300 inches)

11008

  • 4 of Super Grease - 19-1750-001
  • 2 of Metal Sleeves - 60831 (3/4 X .083 X 3.120 inches)
  • 4 of Front Spring Eye Bushings - 61148
  • 4 of Rear Spring Eye Bushings - 61150
  • 4 of Shackle Frame Bushings - 61151

11120

  • 2 of Front Sway Sway Bar Bushings - 62216
  • 1 of Super Grease - 19-1750-001

11121

  • 2 of Sway Bar Bushings - 62217
  • 1 of Super Grease - 19-1750-001

19408

  • 8 of Endlink Bushings - 60353
  • 8 of Flat Washers
  • 2 of Metal Sleeves - 60520 (9/16 X .083 X 2.625 inches) (3/8MIN ID)
  • 2 of Hex Bolts - 1137 (3/8-16 X 7 inches)
  • 2 of Nylon Lock Nuts

11704

  • 2 of Front Upper Spring Coil Isolators - 60604

191312

  • 2 of Front Upper Control Arm Bump Stops - 67021
  • 2 of Flat Washers - 41 (3/8 inch)
  • 2 of Nylon Lock Nuts - 1125 (3/8-16 inch)

Why Urethane?
Production vehicles are built using rubber bushings in control arms, strut arms, leaf springs, body mounts, motor mounts, transmission mounts, sway bars and shocks. Additionally, rubber components can be found as coil spring pads, leaf spring pads and suspension bump stops. While rubber components offer a soft side, for typical driving conditions, they tend to deteriorate rapidly from exposure to the elements. This contributes to premature component failure, resulting in a “spongy” ride and loss of performance handling. Urethane is impervious to gas and oil and will not rot and is stronger than rubber.

Improved Handling and Performance
Due to the firmness of our specially formulated urethane, vehicle owners that have upgraded to PROTHANE Total Kits and Components have experienced better handling, cornering and a firmer suspension feel. PROTHANE a “must” upgrade for High-Performance vehicles where improved performance and durability are desired.

Installation Made Easy
PROTHANE products are made to exact specifications and are direct replacements for original rubber bushings and components. No special tools are required, standard tools and equipment replace factory units.

Urethane Colors
PROTHANE Products are cast in RED and BLACK urethane. The Hardness/Durometer are identical for both colors is the same and there is no difference in performance. Color is a matter of preference. All part numbers are RED urethane products. Part numbers followed by BL indicate black urethane.

Shells/Sleeves
PROTHANE™ has a complete shell program for most popular applications. Many of our control arm bushing kits come complete with new shells. However, in some applications, the original metal shells will need to be reused.

Special Lubrication
PROTHANE Super Grease™ eliminates squeaking that may occur if not applied. Super Grease™ contains versatile waterproof, non-melting Teflon® specially formulated for urethane to seal out water and lubricate under the most adverse conditions. It provides superior adhering and extreme pressure qualities for optimum no- squeak performance. All kits come complete with instructions and an ample supply of PROTHANE Super Grease™
