Magnum 500 Wheel, 17x8" Satin Aluminum, Set of 4 With Center Caps Emblems Only & Lug Nuts, 1968-74 AMC Javelin, Javelin AMX, AMX - Drop ships in approx. 1-4 weeks



Buying a complete set saves 5% (pkg price shown). The Magnum 500 17x8" wheel resembles the factory Magnum 500 wheel you remember.  The larger size allows you to step up to a 17" Z-rated 45-series tire with a square shoulder. This will vastly improve your driving experience with shorter stops, more steering feel with quicker response and more confident and predictable handling.

  • Iconic 5-spoke design similar to the original
  • Satin aluminum finish with satin black center
  • Precision 1-piece cast aluminum alloy construction
  • CNC machined details for a show winning look
  • Tested to strict SAE J2530 standards
  • Includes (4) satin finish cast aluminum Magnum 500 wheels, (4) center caps, (4) reproduction original style American Motors center cap emblems, and (4) reproduction original style AMC stainless chrome lug nuts
  • NOTE: Longer wheel studs may be required (not included). Not returnable once mounted. Mounting, balancing, & tires not included.


  • P/N:  AMCM50017X8SA-4
  • Weight:  20 lbs. per wheel
  • Finish:  Satin Black/Satin
  • Balancing Required:  Lug centric (where balancing adapter goes through the lug holes)
  • Wheel Weights Recommended:  Adhesive style, on the inside of the rim (not included)
  • Warranty:  1-year manufacturer
  • Tires Recommended:  245x45ZRx17 with 25.67" overall diameter
  • Cleaning Recommended:  Soap and water
  • Wheel Backspace Measuring Instructions
AMC, American Motors, Rambler
Models Years
AMX 1968-1970
Javelin 1968-1974
Javelin AMX 1971-1974
